Home /Products/OLED Display/1.54 Inch Monochrome OLED Display Module 128x64 Dots CH1116 IIC Interface

1.54 Inch Monochrome OLED Display Module 128x64 Dots CH1116 IIC Interface

1000
MOQ
DISCUSSABLE
Price
1.54 Inch Monochrome OLED Display Module 128x64 Dots CH1116 IIC Interface
Features Gallery Product Description Chat Now
Features
Specifications
Durability: Varies, Typically Between 20,000-100,000 Hours
Operating Temp: -40°C ~ +70°C
Panel Size: 1.54 Inch (diagonal)
Lcm Interface: I2C
Type: OLED
Response Time: Varies, Typically Between 0.01-0.1 Ms
Viewing Angle: Varies, Typically Between 160-178 Degrees
Weight: Varies, Typically Between 10-100 Grams
Name: OLED Display
Highlight:

Monochrome OLED Display 1.54 Inch

,

Monochrome OLED Display Module

,

Monochrome OLED Module 128x64
Basic Infomation
Place of Origin: China
Brand Name: BBI
Certification: ISO9001 RoHS
Model Number: BBI-001
Payment & Shipping Terms
Packaging Details: CARTON
Delivery Time: 3-4WEEKS
Payment Terms: T/T
Supply Ability: 100000/MONTH
Product Description
1.54 Inch Monochrome OLED Display Module 128x64 Dots CH1116 IIC Interface
Product Overview

High-quality 1.54-inch monochrome OLED display module featuring 128x64 pixel resolution and CH1116 controller with I2C interface.

Display Specifications
  • Display Type: Monochrome OLED (Black/White)
  • Resolution: 128x64 pixels
  • Controller: CH1116
  • Interface: I2C
I2C Interface Pinout
  • VCC: Power supply (3.3V or 5V)
  • GND: Ground
  • SDA: Serial Data Line (I2C)
  • SCL: Serial Clock Line (I2C)
  • RESET: Reset pin (optional for I2C)
Technical Parameters
Parameter Value
Brand Name Bibuke
Display Mode OLED (Organic Light Emitting Diode)
Display Color Blue or White
Panel Size 1.54 Inch
Dot Matrix 128*64 Pixels
Module Size 42.4(W) x 38.0(H) x 3.9(D) mm
Active Area 35.06(W) x 17.52(H) mm
Dot Size 0.254(W)*0.254(H) mm
Dot Pitch 0.274(W)*0.274(H) mm
Drive IC CH1116
Interface I2C
Operating Temperature -40~+70℃
Drive Method 3~5V
PIN Header Optional
Product Images
1.54 Inch Monochrome OLED Display Module 128x64 Dots CH1116 IIC Interface 0 1.54 Inch Monochrome OLED Display Module 128x64 Dots CH1116 IIC Interface 1 1.54 Inch Monochrome OLED Display Module 128x64 Dots CH1116 IIC Interface 2
Packaging & Shipping

Packaging: Carton boxes, cupboard, EPE, blister tray. Packaging method depends on product size and customer requirements.

1.54 Inch Monochrome OLED Display Module 128x64 Dots CH1116 IIC Interface 3

Shipping: Available via DHL, FedEx, EMS, UPS, air shipping, or sea shipping according to customer preference.

1.54 Inch Monochrome OLED Display Module 128x64 Dots CH1116 IIC Interface 4
Frequently Asked Questions
Can you customize the LCD display size and specifications?

Yes, we can customize based on your specifications or drawing. If you don't have specifications, we can recommend suitable options or create custom solutions.

Can you modify existing display content or size?

For segment type LCD modules, modifying outline size or display content requires creating new tooling for a custom LCD glass module.

What is the lead time for tooling?

Typically 15-25 days after drawing confirmation and tooling charge payment. Exact timing will be confirmed upon drawing approval.

Do you provide samples?

Yes, sample orders are available for evaluation.

What is the production lead time?

For standard products in stock: 1 day after payment. For custom mass production: 15-30 days (we'll inform you if we can complete earlier).

Our Services
  • Free repair within one year after shipment
  • Replacement within 30 days for product issues
  • Custom branding (logo and model number printing)
  • Competitive shipping rates through established partnerships
  • Professional technical support and after-sales service
  • Rigorous quality control and testing before shipment
  • 24-hour response time for customer inquiries
  • Customization services based on your specifications
Product Applications
  • Household Appliances: Refrigerators, air conditioners, water heaters, microwave ovens, etc.
  • Communication Equipment: Telephones, interphones, fax machines, wireless wifi
  • Automotive Electronics: On-board entertainment systems, navigation, cameras
  • Instruments: Water meters, electric meters, multimeters, electronic scales
  • Fitness Equipment: Treadmills, fitness bikes, electronic sphygmomanometers
  • Financial: POS machines, banknote counting machines, tax control invoice machines
  • Consumer Electronics: MP3 players, electronic dictionaries, calculators
Product Demonstration

1.54 Inch Monochrome OLED Display Module 128x64 Dots CH1116 IIC Interface 5
