1.7 Inch 128 * 64 LCD Display FFSTN Negative 1.8V 21 PIN LCD Display Parallel Interface

1000
MOQ
DISCUSSABLE
Price
1.7 Inch 128 * 64 LCD Display FFSTN Negative 1.8V 21 PIN LCD Display Parallel Interface
Features Gallery Product Description Chat Now
Features
Specifications
Voltage: 3.0V
Dot Matrix: 128*64 Dots
Viewing Angle: 160 Degrees
Fpc Number: 21PIN
Driver IC: ST7567A
Active Area: 38.00(W)* 22.380(H) Mm
Name: 128x64 LCD Display
Highlight:

1.7 Inch 128 * 64 LCD Display

,

1.8V 21 PIN LCD Display

,

21 PIN LCD Display 12864
Basic Infomation
Place of Origin: China
Brand Name: BBI
Certification: ISO9001 RoHS
Payment & Shipping Terms
Packaging Details: CARTON
Delivery Time: 3-4WEEKS
Payment Terms: T/T
Supply Ability: 100000/MONTH
Product Description
1.7 Inch 128 * 64 LCD Display FFSTN Negative 1.8V 21 PIN LCD Display Parallel Interface
Product Description
FFSTN (Film-Film Super Twisted Nematic) is an advanced form of STN (Super Twisted Nematic) LCD technology, where two layers of film are used in the liquid crystal structure. This design enhances contrast, viewing angles, and image clarity compared to standard STN.
  • Better Contrast: Higher contrast ratios, making the display easier to read in various lighting conditions.
  • Improved Viewing Angles: FFSTN displays allow viewing from more angles with less distortion compared to standard STN displays.
  • Color Options: The display is typically monochrome (black on light background or vice versa), but backlighting can be different colors (e.g., white, blue, or green) for enhanced visibility in low-light conditions.
Detailed Parameters
Parameter Value
Product Description COG Graphic LCD Display
Model Brand Bibuke
LCD Type FFTN(Black), Negative
Polarizer Type Transmissive
Viewing Angle 12 O'clock
Resolution 128x64 dots
Drive Method 1/65 Duty, 1/9 Bias
Working Voltage 1.8V
Operating Temperature -20~+70℃
Storage Temperature -30~+80℃
FPC Connector 21PIN, soldering type
FPC Pitch 0.8mm
Connector COG+FPC
Driver IC ST7567A
Interface 8-bit parallel
Backlight Type 2-LEDs, White
Power Consumption VF=1.8V, IF=30mA
Outline Dimension 45.00(W)* 31.60(H)* 3.00(T) mm
View Area 40.00(W)* 22.00(H) mm
Active Area 38.00(W)* 22.380(H) mm
Dot Size 0.282(W)* 20.98(H) mm
Dot Pitch 0.432(W)* 0.463(H) mm
1.7 Inch 128 * 64 LCD Display FFSTN Negative 1.8V 21 PIN LCD Display Parallel Interface 0 1.7 Inch 128 * 64 LCD Display FFSTN Negative 1.8V 21 PIN LCD Display Parallel Interface 1
Packaging & Shipping
Packaging: Carton boxes, Cupboard, EPE, Blister Tray. Packaging method depends on product size and customer requirements. Different countries have different packaging requirements.
1.7 Inch 128 * 64 LCD Display FFSTN Negative 1.8V 21 PIN LCD Display Parallel Interface 2
Shipping: Express via DHL, Fedex, EMS, UPS, air shipping, or sea shipping. Any shipping method preferred by customer.
1.7 Inch 128 * 64 LCD Display FFSTN Negative 1.8V 21 PIN LCD Display Parallel Interface 3
Payment Method: Various payment options available.
1.7 Inch 128 * 64 LCD Display FFSTN Negative 1.8V 21 PIN LCD Display Parallel Interface 4
FAQ
1. I want the LCD display 8 digits and the outline size is 65x30x2.8mm?
Answer: No problem. Please send us your specification/drawing. If you don't have specifications, you can provide samples; we will recommend suitable products or customize based on your requirements.
2. This LCD is what we want, but it's too big. Do you have smaller sizes? The display content needs minor changes.
Answer: For segment type LCD modules, modifying outline size or display content requires a new LCD glass module with new tooling.
3. This LCD display is HTN type, but I want STN type. Can you make it?
Answer: Yes, we can change the type as per your request.
4. I want to customize a new LCD module. Can you do it?
Answer: Yes, we can. Please send your drawing. If unavailable, provide outline size, display information (glass thickness, polarizer, display type, connector mode, storage temp, operating temp, supply voltage, viewing direction, drive condition), and we'll customize for you.
5. What is the lead time for tooling?
Answer: Typically 15-25 days after drawing confirmation and tooling charge payment. Exact time will be confirmed after drawing approval.
6. Can you send samples for checking?
Answer: Yes, sample orders are available.
7. What is the lead time?
Answer: For standard products in stock, 1 day after payment. For special mass production, 15-30 days. We'll inform you if we can finish earlier.
Our Services
  • Free repair within one year after shipment
  • Replacement within 30 days for product problems
  • Custom logo and model number printing
  • Discounted shipping rates through long-term partnerships
  • Professional technical support and after-sales service
  • All products inspected and tested before shipment
  • 24-hour response to customer inquiries
  • Custom LCD display solutions based on your specifications
Product Applications
  • Household appliances: Refrigerators, air conditioners, fans, heaters, water heaters, electric blankets, air purifiers, washing machines, dryers, vacuum cleaners, microwave ovens, cookers, rice cookers, etc.
  • Communication equipment: Telephones, interphones, fax machines, wireless wifi
  • Automotive electronics: On-board entertainment systems, car fault detectors, navigation systems, car audio, reverse radar, cameras, anti-theft devices
  • Instruments: Water meters, electric meters, multimeters, electronic scales, pressure meters, temperature meters, flow meters, display instruments
  • Fitness equipment: Treadmills, waist machines, fitness bikes, training devices, pedometers, electronic sphygmomanometers, weighing scales
  • Financial: Tax control cash machines, POS machines, USB-key cheque printers, banknote counting machines
  • Consumer electronics: MP3/MP4 players, DVDs, electronic dictionaries, e-readers, learning machines, electronic clocks, calculators
Features: High resolution, high definition, high brightness, cost-effective, energy efficient, wide temperature range operation (positive/negative)

1.7 Inch 128 * 64 LCD Display FFSTN Negative 1.8V 21 PIN LCD Display Parallel Interface 5
