2.48 Inch Graphic LCD Display 128x64 Pixels STN Yellow Green With White Backlight

1000
MOQ
DISCUSSABLE
Price
2.48 Inch Graphic LCD Display 128x64 Pixels STN Yellow Green With White Backlight
Features Gallery Product Description Chat Now
Features
Specifications
Name: Graphic LCD Display
Fpc: 12pin
Voltage: 3.0V
Operating Temperature: -20°C To 70°C
Dot Matrix: 128*64 Dots
Driver Ic: ST7567
Display Type: LCD
Highlight:

2.48 Inch Graphic LCD Display

,

Graphic LCD Display 128x64

,

White Backlight LCD Display 12864
Basic Infomation
Place of Origin: China
Brand Name: BBI
Certification: ISO9001 RoHS
Payment & Shipping Terms
Packaging Details: CARTON
Delivery Time: 3-4WEEKS
Payment Terms: T/T
Supply Ability: 100000/MONTH
Product Description
2.48 Inch Graphic LCD Display 128x64 Pixels STN Yellow Green With White Backlight
This high-quality 2.48-inch graphic LCD display features 128x64 pixel resolution with STN yellow-green color and white backlight, ideal for various industrial and consumer applications.
How to Use
  • Powering the Display: Ensure correct operating voltage (3.3V). For 5V systems, use a level shifter for SPI signals.
  • Communication Interface: Supports SPI interface (SCK, MOSI, CS, A0/D/C, RST) and some parallel communication.
  • Library & Code Support: Compatible with Arduino libraries (U8g2, Adafruit GFX) and Raspberry Pi Python libraries (Luma.LCD).
  • Displaying Graphics/Text: Use buffer for pixel data transfer via SPI. Supports bitmap graphics conversion.
  • Initialization Sequence: Requires specific ST7567 initialization including display ON/OFF, contrast adjustment, and addressing commands.
Detailed Parameters
Parameter Value
Product Description COG Graphic LCD Display
Model Number GY12864-2452
LCD Type STN(Y-G), Positive
Polarizer Type Transmissive
Viewing Angle 12 O'clock
Resolution 128x64 dots
Drive Method 1/65 Duty, 1/9 Bias
Working Voltage 3.0V
Operating Temperature -20~+70℃
Storage Temperature -30~+80℃
FPC Connector 12PIN, socket type
FPC Pitch 0.5 mm
Connector COG+FPC
Driver IC ST7567
Interface SPI
Backlight Type 3-LEDs, White
Power Consumption VF=3.0V, IF=45mA
Outline Dimension 67.00(W)* 43.50(H)* 5.15(T) mm
View Area 62.00(W)* 32.00(H) mm
Dot Size 0.42(W)* 0.42(H) mm
2.48 Inch Graphic LCD Display 128x64 Pixels STN Yellow Green With White Backlight 0 2.48 Inch Graphic LCD Display 128x64 Pixels STN Yellow Green With White Backlight 1 2.48 Inch Graphic LCD Display 128x64 Pixels STN Yellow Green With White Backlight 2
Packaging & Shipping
Packaging: Carton boxes, cupboard, EPE, blister tray. Custom packaging available based on product size and customer requirements. 2.48 Inch Graphic LCD Display 128x64 Pixels STN Yellow Green With White Backlight 3
Shipping: Available via DHL, FedEx, EMS, UPS, air shipping, or sea shipping based on customer preference. 2.48 Inch Graphic LCD Display 128x64 Pixels STN Yellow Green With White Backlight 4
Payment Method: Various payment options available. 2.48 Inch Graphic LCD Display 128x64 Pixels STN Yellow Green With White Backlight 5
FAQ
I want the LCD display 8 digits and the outline size is 65x30x2.8mm?
We can recommend suitable products based on your specifications or samples. Custom solutions are available.
This LCD is just what we want, but it is big size, do you have any smaller size?
For segment type LCD modules, we can create new tooling for modified sizes or display content.
This LCD display is HTN type, but I want STN type, can you make?
Yes, we can modify the display type according to your requirements.
I want to customize a new LCD module. Can you do?
Yes, we can customize based on your specifications or drawings.
What is leading time for tooling?
Typically 15-25 days after drawing confirmation and tooling payment.
Can you send us samples for checking?
Yes, sample orders are available.
What is the Leading Time?
1 day for stock items, 15-30 days for mass production of custom orders.
Our Services
  • Free repair within one year after shipment
  • Replacement within 30 days for product issues
  • Custom logo and model number printing
  • Competitive shipping rates through partner companies
  • Professional technical support and after-sales service
  • Rigorous quality inspection before shipment
  • 24-hour response to customer inquiries
  • Custom LCD display solutions available
Product Applications
  • Household appliances: refrigerators, air conditioners, washing machines
  • Communication equipment: telephones, interphones, fax machines
  • Automotive electronics: entertainment systems, navigation devices
  • Instruments: water meters, electric meters, multimeters
  • Fitness equipment: treadmills, training devices, pedometers
  • Financial devices: POS machines, banknote counting machines
  • Consumer electronics: MP3 players, electronic dictionaries, calculators

2.48 Inch Graphic LCD Display 128x64 Pixels STN Yellow Green With White Backlight 6
