2.15 Inch 128x64 LCD Display COG Dot Matrix LCD Display FSTN ST7567 10PIN Socket Type

1000
MOQ
DISCUSSABLE
Price
2.15 Inch 128x64 LCD Display COG Dot Matrix LCD Display FSTN ST7567 10PIN Socket Type
Features Gallery Product Description Chat Now
Features
Specifications
Name: 128x64 LCD Display
Dimensions: 93mm X 70mm X 12mm
Operating Temperature: -10°C To 60°C
Fpc Number: 10PIN
Display Size: 128x64
Driver Ic: ST7567
Backlight Type: LED
Vdd: 2.8V
Resolution: 128x64
Highlight:

2.15 Inch 128x64 LCD Display

,

FSTN LCD Display 128x64

,

COG Dot Matrix LCD Display
Basic Infomation
Place of Origin: China
Brand Name: BBI
Certification: ISO9001 RoHS
Payment & Shipping Terms
Packaging Details: CARTON
Delivery Time: 3-4WEEKS
Payment Terms: T/T
Supply Ability: 100000/MONTH
Product Description
2.15 Inch 128x64 LCD Display COG Dot Matrix LCD Display FSTN ST7567 10PIN Socket Type
Key Features
  • Resolution: 128x64 pixels for displaying basic graphics, text, and simple animations
  • COG Technology: Chip-on-Glass design for thinner profile and cost efficiency
  • Display Type: Graphic LCD capable of custom images and text at any position
  • Interface: Compatible with SPI or I2C for easy microcontroller integration
  • Power Consumption: Low-power operation suitable for battery-powered devices
Detailed Parameters
Parameter Value
Product Description Monochrome COG Graphic LCD Display
Model Brand Bibuke
LCD Type FSTN(Gray), Positive
Polarizer Type Transmissive
Viewing Angle 6 O'clock
Resolution 128x64 dots
Drive Method 1/64 Duty, 1/7 Bias
Working Voltage 2.8V
Operating Temperature -10~+60℃
Storage Temperature -20~+60℃
FPC Connector 10PIN, ZIF type
FPC Pitch 1.0 mm
Driver IC ST7567
Interface SPI
Backlight Type LEDs, White or Blue
Outline Dimension 58.5(W)* 39.7(H)* 5.2(T) mm
View Area 53.6(W)* 28.6(H) mm
Active Area 48.61(W)* 24.93(H) mm
2.15 Inch 128x64 LCD Display COG Dot Matrix LCD Display FSTN ST7567 10PIN Socket Type 0 2.15 Inch 128x64 LCD Display COG Dot Matrix LCD Display FSTN ST7567 10PIN Socket Type 1
Packaging & Shipping

Packaging: Carton boxes, Cupboard, EPE, Blister Tray. Packaging method depends on product size and customer requirements.

2.15 Inch 128x64 LCD Display COG Dot Matrix LCD Display FSTN ST7567 10PIN Socket Type 2

Shipping: Available via DHL, Fedex, EMS, UPS, air shipping, or sea shipping according to customer preference.

2.15 Inch 128x64 LCD Display COG Dot Matrix LCD Display FSTN ST7567 10PIN Socket Type 3
Frequently Asked Questions
Can I get a custom LCD display with different specifications?

Yes, we can customize LCD displays based on your specifications or samples. Please provide your requirements or drawings.

Can you modify the display type (e.g., from HTN to STN)?

Yes, we can change the display type according to your requirements.

What is the lead time for custom orders?

Standard products ship within 1 day if in stock. Custom orders typically take 15-30 days after drawing confirmation and payment.

Do you provide samples?

Yes, sample orders are available for evaluation.

Our Services
  • 1-year free repair service
  • 30-day replacement for defective products
  • Custom logo and model number printing
  • Professional technical support and after-sales service
  • Quality inspection before shipment
  • Custom LCD display solutions
Product Applications
  • Household appliances: refrigerators, air conditioners, washing machines
  • Communication equipment: telephones, interphones, fax machines
  • Automotive electronics: navigation systems, car audio, cameras
  • Instruments: water meters, electric meters, multimeters
  • Fitness equipment: treadmills, fitness bikes, pedometers
  • Financial devices: POS machines, banknote counters
  • Consumer electronics: MP3 players, electronic dictionaries, calculators
