4.3 Inch IPS TFT LCD Panel 6 O'Clock 480x272 Dots ST7282 40 Pin RGB Interface

1000
MOQ
DISCUSSABLE
Price
4.3 Inch IPS TFT LCD Panel 6 O'Clock 480x272 Dots ST7282 40 Pin RGB Interface
Features Gallery Product Description Chat Now
Features
Specifications
Active Area: 95.04(W)×53.856(V) Mm
Led Life: 50000 Hours
Brightness: 250 Nits
Product: 4.3 Inch IPS TFT LCD Display
Logic Voltage: 2.5V-3.3V
Colors: 262K
Aspect Ratio: 16:9
Backlight Leds: 8LEDs
Name: IPS TFT LCD Display
Highlight:

4.3 Inch TFT LCD Panel

,

IPS TFT LCD Panel

,

40 Pin TFT Display RGB Interface
Basic Infomation
Place of Origin: China
Brand Name: BBI
Certification: ISO9001 RoHS
Model Number: BBI-001
Payment & Shipping Terms
Packaging Details: CARTON
Delivery Time: 3-4WEEKS
Payment Terms: T/T
Supply Ability: 100000/MONTH
Product Description
4.3 Inch IPS TFT LCD Panel 6 O'Clock 480x272 Dots ST7282 40 Pin RGB Interface
Key Features
  • TN Panel Technology: Twisted Nematic (TN) panels offer fast response times, ideal for gaming and dynamic applications.
  • Screen Size: 4.3-inch diagonal size provides a balance between compactness and display area.
  • Resolution: 480x272 pixels for clear display of user interfaces and basic graphics.
Technical Specifications
Item Specification
Product Name 4.3 Inch TFT display
LCD Type TN, Transmissive
Viewing Angle 6 O'clock
Display Mode Normally Black
Resolution 480x272 dots
Operating Temperature -20~+70℃
Storage Temperature -30~+80℃
FPC Connector 40PIN, socket type
FPC PITCH 0.5mm
Driver IC(COG) ST7282
Interface Parallel RGB 24-Bit
Backlight Type 7-LED, White, parallel
Luminance 300 cd/m2
Outline Dimension 105.5(W)* 67.2(H)* 3.0(D) mm
Active Area 95.04(W)* 53.86(H) mm
4.3 Inch IPS TFT LCD Panel 6 O'Clock 480x272 Dots ST7282 40 Pin RGB Interface 0 4.3 Inch IPS TFT LCD Panel 6 O'Clock 480x272 Dots ST7282 40 Pin RGB Interface 1
Packaging & Shipping

Packaging: Carton boxes, Cupboard, EPE, Blister Tray. Packaging method can be customized according to customer requirements.

4.3 Inch IPS TFT LCD Panel 6 O'Clock 480x272 Dots ST7282 40 Pin RGB Interface 2

Shipping: Available via DHL, Fedex, EMS, UPS, air shipping, or sea shipping.

4.3 Inch IPS TFT LCD Panel 6 O'Clock 480x272 Dots ST7282 40 Pin RGB Interface 3
Frequently Asked Questions
Can you customize the LCD display size and specifications?

Yes, we can customize based on your specifications or samples. Please provide your requirements or drawings.

Can you change the LCD type from HTN to STN?

Yes, we can modify the LCD type according to your requirements.

What is the lead time for custom tooling?

Typically 15-25 days after drawing confirmation and tooling payment.

Do you provide samples?

Yes, sample orders are available for standard products.

Our Services
  • Free repair within one year
  • Replacement within 30 days for defective products
  • Custom logo and model number printing
  • Competitive shipping rates
  • Professional technical support
  • Rigorous quality inspection before shipment
  • 24-hour customer service response
  • Full customization capabilities
Product Applications
  • Household appliances: Refrigerators, air conditioners, washing machines, etc.
  • Communication equipment: Telephones, interphones, fax machines
  • Automotive electronics: Navigation systems, car audio, reverse cameras
  • Instruments: Water meters, electric meters, measuring devices
  • Fitness equipment: Treadmills, exercise bikes, weighing scales
  • Financial devices: POS machines, tax control invoice machines
  • Consumer electronics: MP3 players, electronic dictionaries, calculators

4.3 Inch IPS TFT LCD Panel 6 O'Clock 480x272 Dots ST7282 40 Pin RGB Interface 4
