Name: 3.97 Inch IPS LCD TFT Display 480x800 Dots GC9503 24PIN FPC With MIPI Interface
Brand: Dongguan Bibuke Electronic Technology Co., Ltd.
SKU: BBI-001
Availability: InStock

Features Gallery Product Description Chat Now

Features

Specifications

Refresh Rate: 60 Hz

Backlight Type: LED

Interface: MIPI

Color Gamut: 72% NTSC

Luminance: 300 Cd/m2

Resolution: 480x800 Dots

Name: TFT LCD Display

Highlight:

IPS LCD TFT Display 24PIN

3.97 Inch LCD TFT Screen

MIPI Interface TFT Screen Display

Basic Infomation

Place of Origin: China

Brand Name: BBI

Certification: ISO9001 RoHS

Model Number: BBI-001

Payment & Shipping Terms

Packaging Details: CARTON

Delivery Time: 3-4WEEKS

Payment Terms: T/T

Supply Ability: 100000/MONTH

Gallery

3.97 Inch IPS LCD TFT Display 480x800 Dots GC9503 24PIN FPC With MIPI Interface

Product Description

3.97 Inch IPS LCD TFT Display 480x800 Dots GC9503 24PIN FPC With MIPI Interface

Key Features

Screen Size: 3.97-inch diagonal display provides more space than standard 3.5-inch displays for detailed content and complex GUIs
Resolution: 480×800 pixel resolution delivers sharp, clear visuals for text, images, and animations
Color Depth: 16.7 million colors (24-bit) for rich, vibrant color reproduction
Backlighting: LED backlight ensures excellent brightness and visibility in all lighting conditions

Technical Specifications

Item	Specification
Product Name	3.97 Inch TFT LCD
LCD Type	Normally Black
Viewing Angle	Free
Resolution	480×800 dots
Operating Temperature	-20~+70℃
Storage Temperature	-30~+80℃
FPC Connector	24PIN, ZIF type
FPC Pitch	0.5 mm
Driver IC (COG)	GC9503
Interface	MIPI
Backlight Type	8-LED, White, 160mA
Luminance	300 cd/m²
Outline Dimension	57.14(H)×96.85(V)×2.20(D) mm
Active Area	51.84(H)×86.35(V) mm

Packaging & Shipping

Packaging: Carton boxes, cupboard, EPE, blister tray. Packaging method varies based on product size and customer requirements, complying with different countries' regulations.
