Home /Products/LCD TFT Display/4.45 Inch LCD TFT Display 480x800 Dots GC9503 24PIN MIPI Interface

4.45 Inch LCD TFT Display 480x800 Dots GC9503 24PIN MIPI Interface

1000
MOQ
DISCUSSABLE
Price
4.45 Inch LCD TFT Display 480x800 Dots GC9503 24PIN MIPI Interface
Features Gallery Product Description Chat Now
Features
Specifications
Display Type: TFT LCD
Backlight Technology: LED
Refresh Rate: 60 Hz
Aspect Ratio: 16:9
Contrast Ratio: 1000:1
Resolution: 480x800 Dots
Touchscreen: No
Viewing Angle: FREE
Name: TFT LCD Display
Highlight:

4.45 Inch LCD TFT Display

,

LCD TFT Display 480x800 Dots

,

TFT LCD Module 24PIN
Basic Infomation
Place of Origin: China
Brand Name: BBI
Certification: ISO9001 RoHS
Model Number: BBI-001
Payment & Shipping Terms
Packaging Details: CARTON
Delivery Time: 3-4WEEKS
Payment Terms: T/T
Supply Ability: 100000/MONTH
Product Description
4.45 Inch LCD TFT Display 480x800 Dots GC9503 24PIN MIPI Interface
Key Features
  • Screen Size: 4.45-inch diagonal display provides ample space for detailed information and graphics while maintaining compact dimensions.
  • Resolution: 480×800 pixel resolution delivers sharp, clear visuals for text, graphics, and real-time data display.
  • Color Depth: Supports 16.7 million colors (24-bit) for vibrant, high-fidelity color reproduction.
  • Touchscreen Options: Available with resistive (pressure-sensitive) or capacitive (multi-touch) panels for interactive applications.
  • Backlighting: LED backlight ensures excellent visibility across various lighting conditions.
Technical Specifications
Item Specification
Product Name 4.45 Inch TFT LCD
LCD Type IPS
Viewing Angle Free
Resolution 480×800 dots
Operating Temperature -20~+70℃
Storage Temperature -30~+80℃
FPC Connector 24PIN, ZIF type
Driver IC(COG) GC9503CV
Interface MIPI
Backlight Type 10-LED, White, Vf=15±0.8V, If=40mA
Outline Dimension 60(H)×109(V)×2.15(D) mm
Active Area 55.44(H)×98.64(V) mm
4.45 Inch LCD TFT Display 480x800 Dots GC9503 24PIN MIPI Interface 0 4.45 Inch LCD TFT Display 480x800 Dots GC9503 24PIN MIPI Interface 1

4.45 Inch LCD TFT Display 480x800 Dots GC9503 24PIN MIPI Interface 2

Our Services
  • 1-year free repair service from shipment date
  • 30-day replacement policy for defective products
  • Custom branding options including logo printing and model number labeling
  • Efficient global shipping with discounted rates
  • Professional technical support and responsive after-sales service
  • Rigorous quality control with pre-shipment inspection
  • 24-hour response guarantee for customer inquiries
  • Custom LCD display solutions based on your specifications or drawings
