135x240 Small TFT LCD Display Screen IPS ST7789V 1.14 Inch 13pin Serial Interface

1000
MOQ
DISCUSSABLE
Price
135x240 Small TFT LCD Display Screen IPS ST7789V 1.14 Inch 13pin Serial Interface
Features Gallery Product Description Chat Now
Features
Specifications
Name: Small TFT LCD Display Screen
Panel Type: IPS
Driver Lc: ST7789V2
Viewing Direction: 6 O'clock
Led Pcs: 1 Pcs
Outline Dimension: 17.6(H)*31.0(V)*1.6(D) Mm
Storage Temperature: -30 ~ +80ºC
Highlight:

135x240 Small TFT LCD Display

,

Small TFT LCD Display Screen

,

IPS ST7789V 1.14 Inch
Basic Infomation
Place of Origin: China
Brand Name: BBI
Certification: ISO9001 RoHS
Model Number: BBI-001
Payment & Shipping Terms
Packaging Details: CARTON
Delivery Time: 3-4WEEKS
Payment Terms: T/T
Supply Ability: 100000/MONTH
Product Description
135x240 Small TFT LCD Display Screen IPS ST7789V 1.14 Inch 13pin Serial Interface
Product Description
1. Size and Resolution:
  • Screen Size: Diagonal measurement of 1.14 inches, slightly larger than common 1.06-inch displays while remaining compact.
  • Resolution: Typically 240×135 pixels, a popular resolution for TFT displays in this size range.
2. Backlighting:
  • LED Backlight: White LED illumination for visibility in low-light conditions, with some models offering RGB backlighting options.
3. Example Use Cases:
  • Smartwatches and fitness trackers for displaying time, health data, and notifications
  • Embedded projects with microcontrollers for sensor data visualization and user interfaces
  • Digital toys and handheld gaming devices for portable color graphics
  • Small consumer electronics like media players, alarms, and custom controllers
4. Potential Resolutions and Pixel Density:

With a 240×135 resolution on a 1.14-inch screen, the pixel density is approximately 208 PPI (pixels per inch), providing sharp image quality for small displays.

Basic Parameters:
NO. ITEM SPECIFICATIONS
1 Product Name 1.14 Inch TFT LCD
2 LCD Type IPS
3 Resolution 135×240 dots
4 Operating Temperature -20~+70℃
5 Storage Temperature -30~+80℃
6 FPC Connector 13PIN, soldering type
7 Pitch 0.7 mm
8 Driver IC(COG) ST7789V2
9 Interface 4 SPI
10 Backlight Type 1-LED, White
11 Power Consumption VF=3.0V, IF=20mA
12 Outline Dimension 17.6(H)×31.0(V)×1.6(D) mm
13 Active Area 14.86(H)×24.91(V) mm
135x240 Small TFT LCD Display Screen IPS ST7789V 1.14 Inch 13pin Serial Interface 0 135x240 Small TFT LCD Display Screen IPS ST7789V 1.14 Inch 13pin Serial Interface 1
Products Application Field:
Audio products
Medical equipment
Industrial products
Automobiles
Sports equipment
Watches
Household appliances
Our Services:
  • Free repair within one year after shipment
  • Replacement within 30 days for product defects
  • Custom logo printing and model number labeling
  • Competitive shipping rates through established partnerships
  • Professional technical support and responsive after-sales service
  • Rigorous quality inspection before shipment
  • 24-hour response time for customer inquiries
  • Custom LCD display manufacturing based on specifications or drawings
Packaging & Shipping:

Packaging: Carton boxes, cupboard, EPE, blister tray - customized based on product size and customer requirements.

135x240 Small TFT LCD Display Screen IPS ST7789V 1.14 Inch 13pin Serial Interface 2

Shipping: DHL, FedEx, EMS, UPS, air shipping, sea shipping - available according to customer preference.

135x240 Small TFT LCD Display Screen IPS ST7789V 1.14 Inch 13pin Serial Interface 3 135x240 Small TFT LCD Display Screen IPS ST7789V 1.14 Inch 13pin Serial Interface 4
FAQ:
I want the LCD display 8 digits and the outline size is 65×30×2.8mm?

Answer: Please send your specification or drawing. If unavailable, we can recommend suitable standard products or customize based on your requirements.

This LCD is what we want, but it's too large. Do you have smaller sizes?

Answer: For segment type LCD modules requiring size modifications, we can create new tooling to meet your specifications.

This LCD display is HTN type, but I want STN type. Can you make it?

Answer: Yes, we can modify the display type according to your requirements.

I want to customize a new LCD module. Can you do this?

Answer: Yes. Please provide your drawing or specifications including outline size, display information, glass thickness, polarizer type, and operating parameters.

What is the lead time for tooling?

Answer: Typically 15-25 days after drawing confirmation and tooling payment, with exact timing confirmed upon order.

Can you send samples for checking?

Answer: Yes, sample orders are available.

What is the lead time?

Answer: Standard products ship within 1 day if in stock. Custom production takes 15-30 days, with earlier completion updates when possible.
