Va Tn LCD Display No Touch Screen 1600x900
High-performance TN LCD display with 1600x900 resolution, Vop 3.0V, Duty 1/4, and Bias 1/3 configuration.
Technical Specifications
| Optimum Resolution |
1600x900 |
| Type |
TN |
| Widescreen |
Not Widescreen |
| Response Time |
3ms |
| 3D |
Not 3D |
| Interface Type |
VGA |
| Specification |
CE FCC ROHS |
| Trademark |
BBI |
| Origin |
China |
| Display Type |
TN |
| Display Mode |
Positive |
| Polarizer Mode |
Reflective |
| Driving Method |
Vop 3.0V, Duty 1/4, Bias 1/3 |
| Viewing Direction |
12 o'clock |
Mechanical Specifications
| Item |
Specifications |
Unit |
| Dimensional Outline |
42.00±0.20(L) X 20.80±0.20(W) X 2.80(MAX) |
mm |
| Viewing Area |
39.60±0.20 (L)MIN X 16.40(W)MIN |
mm |
| PIN Pitch |
2.00 |
mm |
| PIN Length |
10.00 |
mm |
| Number of PIN |
9 |
---- |
Product Images
Similar Products
Product Applications
Available COB LCD Modules
| Model |
Content CharsXLines |
Module size W x H(mm) |
View area W x H(mm) |
Dot size W x H(mm) |
Character size W x H(mm) |
Driving Method |
Controller LSI or Equiv |
IC Package |
STN-TYPE |
FSTN-TYPE |
Available COG LCD Modules
| Model |
Content (W X H) |
Module size W x H(mm) |
View area W x H(mm) |
Dot size W x H(mm) |
Dot pitch W x H(mm) |
Driving Method |
Controller LSI or Equiv |
IC Package |
STN-TYPE |
FSTN-TYPE |
Packaging & Shipping
Packaging: Carton boxes, Cupboard, EPE, Blister Tray. Packaging method depends on product size and customer requirements, which may vary by country.
Shipping: Available via DHL, Fedex, EMS, UPS, air shipping, or sea shipping - whichever method you prefer.
Payment Method:
Frequently Asked Questions
1. I want the LCD display 8 digits and the outline size is 65x30x2.8mm?
Answer: No problem. Please send us your specification/drawing. If you don't have specifications, you can provide samples; we'll recommend suitable standard products or customize based on your requirements.
2. This LCD is what we want, but the size is too big. Do you have smaller sizes? The display content needs minor changes.
Answer: For segment type LCD modules requiring size or content modifications, we need to create new LCD glass modules with custom tooling.
3. This LCD display is HTN type, but I want STN type. Can you make it?
Answer: Yes, we can modify the display type according to your requirements.
4. I want to customize a new LCD module. Can you do this?
Answer: Yes, we can customize LCD modules. Please provide your drawing or specifications including outline size, display information, glass thickness, polarizer type, connector mode, temperature requirements, voltage, viewing direction, and drive conditions.
5. What is the lead time for tooling?
Answer: Typically 15-25 days after drawing confirmation and tooling payment. Exact time will be confirmed after reviewing your specifications.
6. Can you send samples for evaluation?
Answer: Yes, sample orders are available.
7. What is the lead time?
Answer: For standard products in stock: 1 day after payment. For special mass production: 15-30 days. We'll inform you if we can complete earlier.
Our Services
- Free repair within one year after shipment
- Replacement within 30 days for product-related issues
- Custom logo and model number printing available
- Discounted shipping rates through our partner carriers
- Professional technical support and responsive after-sales service
- All products inspected and tested by engineers before shipment
- 24-hour response time for customer inquiries
- Custom LCD display solutions based on your specifications
