Home /Products/VA LCD Display/BBI Negative VA LCD Module White Character LCD Display 4.5V 34PIN For Feeder

BBI Negative VA LCD Module White Character LCD Display 4.5V 34PIN For Feeder

1000
MOQ
DISCUSSABLE
Price
BBI Negative VA LCD Module White Character LCD Display 4.5V 34PIN For Feeder
Features Gallery Product Description Chat Now
Features
Specifications
Name: VA LCD Display
Small Orders: Accepted
Connector: Pin Or Zebra
Driving Condition: 4.5 V
LED Backlight: White
Polarizer Type: Transflective/Transmissive/Reflective
Viewing Angle: 12O'clock
Highlight:

Negative VA LCD Module

,

VA LCD Module 34PIN

,

Character LCD Display 4.5V
Basic Infomation
Place of Origin: China
Brand Name: BBI
Certification: ISO9001 RoHS
Model Number: BBI-001
Payment & Shipping Terms
Packaging Details: CARTON
Delivery Time: 3-4WEEKS
Payment Terms: T/T
Supply Ability: 100000/MONTH
Product Description
BBI Negative VA LCD Module White Character LCD Display 4.5V 34PIN For Feeder
Product Description
Steps to Develop a Custom VA LCD Screen:
1. Define Display Requirements
  • Type of Display: Segment-based for numbers, symbols, or simple icons. Graphical for more complex images or dynamic content.
  • Size and Shape: Define dimensions based on your device's design. Consider thickness for slim or compact designs.
  • Resolution: Specify the number of segments or pixels for your application.
  • Viewing Angle: Ensure a wide viewing angle (up to 170° for VA technology).
Detailed Parameters
Model Description Negative VA LCD Module LCD type Segmented Display
Module size 32.42(W)* 21.7(H)* 2.0(T) mm Display mode VA, Negative
LCD viewing area 29.42(W)* 14.70(H) mm Polarizer type Transmissive
Operating temp. 0~+50℃ LED backlight White
Drive method 1/4 Duty, 1/3 Bias Working voltage 4.5V
Viewing angle 12 O'clock Connection Way PIN, 34 numbers
BBI Negative VA LCD Module White Character LCD Display 4.5V 34PIN For Feeder 0 BBI Negative VA LCD Module White Character LCD Display 4.5V 34PIN For Feeder 1 BBI Negative VA LCD Module White Character LCD Display 4.5V 34PIN For Feeder 2
Packaging & Shipping

Packaging: Carton boxes, Cupboard, EPE, Blister Tray. Packaging method depends on product size and customer requirements, which may vary by country.

BBI Negative VA LCD Module White Character LCD Display 4.5V 34PIN For Feeder 3

Shipping: Express via DHL, Fedex, EMS, UPS, air shipping, or sea shipping. Any shipping method preferred by customer.

BBI Negative VA LCD Module White Character LCD Display 4.5V 34PIN For Feeder 4
Payment Method
BBI Negative VA LCD Module White Character LCD Display 4.5V 34PIN For Feeder 5
FAQ
1. I want the LCD display 8 digits and the outline size is 65x30x2.8mm?

Answer: No problem. Please send us your specification/drawing. If unavailable, we can recommend suitable standard products or customize based on your requirements.

2. This LCD is what we want, but it's too big. Do you have smaller size?

Answer: For segment type LCD modules requiring size or content modification, we need to create new tooling for a custom LCD glass module.

3. This LCD display is HTN type, but I want STN type, can you make?

Answer: Yes, we can modify the display type according to your request.

4. I want to customize a new LCD module. Can you do?

Answer: Yes. Please send your drawing or provide outline size and display specifications (glass thickness, polarizer, display type, connector mode, temperature range, voltage, viewing direction, drive condition).

5. What is the lead time for tooling?

Answer: Typically 15-25 days after drawing confirmation and tooling payment. Exact time will be confirmed upon drawing approval.

6. Can you send us samples for checking?

Answer: Yes, sample orders are available.

7. What is the Lead Time?

Answer: For standard products in stock: 1 day after payment. For special mass production: 15-30 days. We'll inform you if we can complete earlier.

Our Services
  • Free repair within one year after shipment
  • Replacement within 30 days for product-related issues
  • Custom logo and model number printing available
  • Discounted shipping rates through long-term partnerships
  • Professional technical support and responsive after-sales service
  • All products inspected and tested by engineers before shipment
  • 24-hour response to customer inquiries
  • Custom LCD displays available based on your specifications
Product Applications
  • Household appliances: Refrigerators, air conditioners, fans, heaters, water heaters, electric blankets, air purifiers, washing machines, vacuum cleaners, microwave ovens, rice cookers
  • Communication equipment: Telephones, interphones, fax machines, wireless wifi
  • Automotive electronics: On-board entertainment systems, vehicle navigators, car audio, reverse radar, cameras
  • Instruments: Water meters, electric meters, multimeters, electronic scales, pressure meters, temperature meters
  • Fitness equipment: Treadmills, fitness bikes, training devices, pedometers, electronic sphygmomanometers
  • Financial: Tax control cash machines, POS machines, banknote counting machines
  • Consumer electronics: MP3/MP4 players, DVD players, electronic dictionaries, calculators, electronic clocks

BBI Negative VA LCD Module White Character LCD Display 4.5V 34PIN For Feeder 6
